Alloy 713C/713LC/UNS N07713
Grade: Inconel 713C/713LC/UNS N07713/Alloy 713C/Alloy 713LC/Nickel Alloy 713C/Nickel Alloy 713LC/UNS R30783/W.Nr.2.4650
Sheet/Plate: 0.3mm-150mm
Strip/Foil: 0.02mm-16mm
Pipe: 6mm*0.5mm-1200mm*100mm
Bar: Ф6mm – Ф600mm
Wire: Ф0.01mm – Ф6mm
Others: Forged Rings, Flanges, Elbows, Tees, Reducers etc.
Standard: ASTM/ASME/AMS
- Fast Shipping / Ready Stock
- ISO 9001 Factory
- Custom Cutting
- 100% MTC & SGS Inspection
INCONEL 713C is a cast nickel-based superalloy strengthened by gamma-prime precipitation. It offers excellent creep strength, oxidation resistance and thermal stability, making it suitable for high-temperature turbine applications.
Chemical Composition (wt.%):
| Element | Content |
| Ni | Balance |
| Cr | 12-14 |
| Mo | 3.8-5.2 |
| Nb | 1.8-2.5 |
| Al | 5.5-6.5 |
| Ti | 0.5-1.0 |
Mechanical Properties:
| Property | Typical Value |
| Tensile Strength | ≈900 MPa |
| Yield Strength | ≈700 MPa |
| Elongation | ≈3-6% |
Applications:
- Gas turbine blades
- Aerospace engines
- Turbocharger components
INCONEL 713C is a cast nickel-based superalloy strengthened by gamma-prime precipitation. It offers excellent creep strength, oxidation resistance and thermal stability, making it suitable for high-temperature turbine applications.
Chemical Composition (wt.%):
| Element | Content |
| Ni | Balance |
| Cr | 12-14 |
| Mo | 3.8-5.2 |
| Nb | 1.8-2.5 |
| Al | 5.5-6.5 |
| Ti | 0.5-1.0 |
Mechanical Properties:
| Property | Typical Value |
| Tensile Strength | ≈900 MPa |
| Yield Strength | ≈700 MPa |
| Elongation | ≈3-6% |
Applications:
- Gas turbine blades
- Aerospace engines
- Turbocharger components
