1050A Aluminum Sheet/Coil

Q: Mechanical

Mechanical properties by temper Temper Thickness mm or basis Rm MPa Rp0.2 MPa Elongation % O 0.5–1.5 65–95 20 min 22 min H14 0.5–1.5 105–145 85 min 2 min H24 0.5–1.5 105–145 75 min 4 min H18 0.5–1.5 140 min 120 min 2 min O 3–6 65–95 20 min 29 min H14 3–6 105–145 85 min 5 min H24 3–6 105–145 75 min 8 min Published Yieh sheet limits, not universal values for every product or specification. Elongation gauge length is not identified in the supplier table and must be confirmed for acceptance testing. Thickness intervals reproduce the supplier bands. [3] Temper definitions O is annealed. H14 is strain hardened to half hard; H24 is strain hardened and partially annealed to half hard; H18 is strain hardened to full hard. The same nominal hardness level does not imply identical specification limits.

Grade: 1050A

Coil: 0.3mm-3.0mm

Sheet: 0.3mm-300mm

Width: 50mm-2000mm

Standard: ASTM, AMS, BS etc.

1050A is a commercially pure wrought aluminum grade containing at least 99.50% aluminum. It combines excellent corrosion resistance, high ductility and good electrical and thermal conductivity. Sheet is readily bent, drawn and welded, making it useful for fabricated enclosures, reflective surfaces and heat transfer components. Strength increases through cold working rather than precipitation heat treatment. Its low strength and relatively poor machinability favor formed sheet applications over highly loaded precision parts.

Chemical composition

Weight percent limits. Sources [1–3].

Element	Limit wt %	Element	Limit wt %
Al	99.50 min	Si	0.25 max
Fe	0.40 max	Cu	0.05 max
Mn	0.05 max	Mg	0.05 max
Zn	0.07 max	Ti	0.05 max
Other each	0.03 max	Other total	—

Mechanical properties by temper

Temper	Thickness mm or basis	Rm MPa	Rp0.2 MPa	Elongation %
O	0.5–1.5	65–95	20 min	22 min
H14	0.5–1.5	105–145	85 min	2 min
H24	0.5–1.5	105–145	75 min	4 min
H18	0.5–1.5	140 min	120 min	2 min
O	3–6	65–95	20 min	29 min
H14	3–6	105–145	85 min	5 min
H24	3–6	105–145	75 min	8 min

Published Yieh sheet limits, not universal values for every product or specification. Elongation gauge length is not identified in the supplier table and must be confirmed for acceptance testing. Thickness intervals reproduce the supplier bands. [3]

Temper definitions

O is annealed. H14 is strain hardened to half hard; H24 is strain hardened and partially annealed to half hard; H18 is strain hardened to full hard. The same nominal hardness level does not imply identical specification limits.

Application areas

General fabricated sheet metal and cabinets
Chemical process equipment and compatible service containers
Architectural flashings and panels
Lamp reflectors and cable sheathing
Heat transfer devices and formed food industry containers
