253SMo Stainless Steel Round Pipe

Grade: 253MA/ S31254

Size:

Seamless: 6mm*1mm-720mm*50mm

Welded: 12mm*0.5mm-2000mm*100mm

Coiled: 4mm*0.3mm-32mm*3mm

Standard: ASTM A312, ASTM A213 etc.

Surface: No.1(Pickling), Bright(Polished)

254SMO Stainless Steel Pipe is a super austenitic grade developed for severe chloride-bearing and seawater environments. Its high chromium, molybdenum, and nitrogen contents provide excellent resistance to pitting, crevice corrosion, and stress corrosion cracking. Copper further supports resistance in selected acidic media. 254SMO pipe is widely used in seawater cooling, desalination, pulp bleaching, chemical processing, gas cleaning, and aggressive process piping.

Chemical Composition

Element	Content (wt. %)
C	≤0.020
Si	≤0.80
Mn	≤1.00
P	≤0.030
S	≤0.010
Cr	19.5–20.5
Ni	17.5–18.5
Mo	6.0–6.5
N	0.18–0.25
Other	Cu: 0.5–1.0; Fe: Balance

Mechanical Properties

Condition	Tensile Strength	Yield Strength (0.2%)	Elongation	Hardness
Solution annealed	≥690	≥310	≥35	≤223 HB / ≤96 HRB

Seawater cooling systems
Desalination plants
Chemical processing
Pulp bleaching
Gas cleaning systems
High-chloride pipelines
