Stainless Steel Checker Plate
Grade: 304/304L/316/316L/UNS S30400/UNS S30403/UNS S31600/UNS S31603/W.Nr.1.4301/W.Nr.1.4307/W.Nr.1.4401/W.Nr.1.4403
Standard: ASTM A240/A240M
Thickness: 3.0mm-10.0mm
Width: 1500mm/1800mm/2000mm, cut size are available.
- Fast Shipping / Ready Stock
- ISO 9001 Factory
- Custom Cutting
- 100% MTC & SGS Inspection
A stainless steel floor plate (also known as a checker plate) is a metal sheet with a raised surface pattern (diamonds, tears, checker plate, or similar patterns) designed to reduce the risk of slipping.
It combines strength, durability, and corrosion resistance, making it ideal for industrial, commercial, outdoor, or high-maintenance environments.
Its resistance to chemicals and repeated washdowns makes it a preferred choice for sectors such as food processing, commercial kitchens, and laboratories.
| Chemical composition | 304 (UNS S30400/ EN1.4301) | 304L (UNS S30403/EN 1.4307) |
| Carbon, Max% | 0.07 | 0.03 |
| Manganese, Max% | 2 | 2 |
| Phosphorus, Max% | 0.045 | 0.045 |
| Sulphur, Max% | 0.03 | 0.03 |
| Silicon, Max% | 0.75 | 0.75 |
| Chromium Range% | 17.5-19.5 | 17.5-19.5 |
| Nickel Range% | 8.0-10.5 | 8.0-12.0 |
| Nitrogen, Max% | 0.1 | 0.1 |
| Chemical composition | 316 (UNS S31600/ EN1.4401) | 316L (UNS S31603/EN 1.4404) |
| Carbon, Max% | 0.08 | 0.03 |
| Manganese, Max% | 2 | 2 |
| Phosphorus, Max% | 0.045 | 0.045 |
| Sulphur, Max% | 0.03 | 0.03 |
| Silicon, Max% | 0.75 | 0.75 |
| Chromium Range% | 16.0-18.0 | 16.0-18.0 |
| Nickel Range% | 10.0-14.0 | 10.0-14.0 |
| Nitrogen, Max% | 0.1 | 0.1 |
| Molybdenum Range% | 2.0-3.0 | 2.0-3.0 |
| Mechanical Properties | 304 | 304L |
| Tensile Min | 75 ksi | 70 ksi |
| Yield Min | 30 ksi | 25 ksi |
| Elongation Min | 40% | 40% |
| Hardness Max | 92 HRB | 92 HRB |
| Mechanical Properties | 316 | 316L |
| Tensile Min | 75 ksi | 70 ksi |
| Yield Min | 30 ksi | 25 ksi |
| Elongation Min | 40% | 40% |
| Hardness Max | 95 HRB | 95 HRB |
Thanks to their textured surface and resistance to corrosion and chemicals, these plates are well suited for:
- Industrial and commercial flooring
- Stairs, ramps, and landings
- Walkways and work platforms
- Heavy equipment, truck steps, and trailers
- Wet, outdoor, or washdown-intensive environments exposed to chemicals


A stainless steel floor plate (also known as a checker plate) is a metal sheet with a raised surface pattern (diamonds, tears, checker plate, or similar patterns) designed to reduce the risk of slipping.
It combines strength, durability, and corrosion resistance, making it ideal for industrial, commercial, outdoor, or high-maintenance environments.
Its resistance to chemicals and repeated washdowns makes it a preferred choice for sectors such as food processing, commercial kitchens, and laboratories.
| Chemical composition | 304 (UNS S30400/ EN1.4301) | 304L (UNS S30403/EN 1.4307) |
| Carbon, Max% | 0.07 | 0.03 |
| Manganese, Max% | 2 | 2 |
| Phosphorus, Max% | 0.045 | 0.045 |
| Sulphur, Max% | 0.03 | 0.03 |
| Silicon, Max% | 0.75 | 0.75 |
| Chromium Range% | 17.5-19.5 | 17.5-19.5 |
| Nickel Range% | 8.0-10.5 | 8.0-12.0 |
| Nitrogen, Max% | 0.1 | 0.1 |
| Chemical composition | 316 (UNS S31600/ EN1.4401) | 316L (UNS S31603/EN 1.4404) |
| Carbon, Max% | 0.08 | 0.03 |
| Manganese, Max% | 2 | 2 |
| Phosphorus, Max% | 0.045 | 0.045 |
| Sulphur, Max% | 0.03 | 0.03 |
| Silicon, Max% | 0.75 | 0.75 |
| Chromium Range% | 16.0-18.0 | 16.0-18.0 |
| Nickel Range% | 10.0-14.0 | 10.0-14.0 |
| Nitrogen, Max% | 0.1 | 0.1 |
| Molybdenum Range% | 2.0-3.0 | 2.0-3.0 |
| Mechanical Properties | 304 | 304L |
| Tensile Min | 75 ksi | 70 ksi |
| Yield Min | 30 ksi | 25 ksi |
| Elongation Min | 40% | 40% |
| Hardness Max | 92 HRB | 92 HRB |
| Mechanical Properties | 316 | 316L |
| Tensile Min | 75 ksi | 70 ksi |
| Yield Min | 30 ksi | 25 ksi |
| Elongation Min | 40% | 40% |
| Hardness Max | 95 HRB | 95 HRB |
Thanks to their textured surface and resistance to corrosion and chemicals, these plates are well suited for:
- Industrial and commercial flooring
- Stairs, ramps, and landings
- Walkways and work platforms
- Heavy equipment, truck steps, and trailers
- Wet, outdoor, or washdown-intensive environments exposed to chemicals
