To address the processing challenges of liquid-metal conductors, the authors reviewed various material modification strategies and printing methods. They focused on adjusting the rheological properties of conductive inks for scalable manufacturing. Adding nanomaterials, carbon nanotubes, or elastomer polymers can increase the liquid metal’s viscosity, allowing it to form stable patterns after deposition.
The review covered methods for removing the surface oxide layer, including mechanical removal, chemical etching, and electrochemical reduction, to establish conductive pathways. Printing approaches ranged from two-dimensional methods such as direct writing and mask printing to three- and four-dimensional manufacturing techniques. For three-dimensional fabrication, direct ink writing (DIW) and digital light processing (DLP) were discussed for producing multilayered and structurally complex electronic components.
Material extrusion was analyzed in terms of the mechanical equilibrium governing deposition. The balance between printing pressure and hydrostatic and interfacial forces is crucial for the liquid metal to form stable lines rather than spreading into droplets.
Impact of Material Composition on Performance
The review highlighted several effects of material composition and processing on functionalized liquid-metal inks. Alloying gallium with indium to form EGaIn can reduce the surface tension from approximately 700 mN/m for pure gallium to about 500-600 mN/m, thereby improving wetting and spreading on polymer substrates. Additionally, incorporating nickel microparticles into EGaIn enabled passive filling of laser-patterned microgrooves, producing surface-embedded circuits that were resistant to mechanical removal.
While the spontaneously formed oxide layer has a resistivity exceeding 10 Ω·cm, it also contributes to structural retention by allowing the liquid metal core to maintain nonspherical shapes and form stable traces. However, the oxide layer increases electrical contact resistance by more than 1,000 times. To overcome this challenge, mechanical or ultrasonic treatment can rupture the oxide layer, establishing conductive pathways, while high-shear mixing can fragment and redistribute the oxide within the ink to improve printability and conductive stability.
Printed devices accommodated substantial mechanical deformation, with a DLP-based approach producing patterns with stretchability above 2,500% while retaining high conductivity. The same approach achieved a resolution of about 20 µm, while electrohydrodynamic printing combined with selective adhesion achieved similarly small minimum line widths, demonstrating the potential to integrate fine conductive patterns into soft electronic devices.
Applications in Wearable Technologies
These manufacturing strategies could support a range of applications in wearable, soft robotic, and human-machine interfaces. Stretchable energy-storage systems, including zinc-ion batteries, have used liquid-metal-based current collectors that accommodate mechanical strain while helping suppress dendrite growth. Other applications include strain sensors and tactile interfaces for electronic skin, including EMG electrodes, ECG monitoring during movement, and e-skin capable of acquiring ECG and EEG signals under sweating and electromagnetic interference. The combination of stretchable conductors, sensors, and energy-storage components could enable self-powered wearable systems for continuous health monitoring.
Future Directions in Liquid Metal Electronics
In summary, fluidic alloys provide a versatile platform for deformable electronic architectures. Addressing their rheological and interfacial properties has enabled the development of printing methods for functional devices, ranging from single-layer conductive traces to multilayer and stimulus-responsive structures. Further development will require more reliable multimaterial integration, scalable and reproducible manufacturing, improved encapsulation to prevent leakage, greater recyclability, and standardized long-term safety and biocompatibility assessments. Continued refinement of printing processes, including potential machine-learning-guided ink design and more versatile ink systems, could expand the use of liquid-metal electronics in healthcare, soft robotics, and human-machine interfaces.
